The linear bearing cage is an essential component of a linear rolling bearing built with the use of linear guides. The main task of the bearing cage is to hold the rolling elements inside the bearing on the guide's raceways in the correct operating position.
Flat plastic single-row bearing cages with crossed bearing rollers
Made of plastic.
Work with R, RD, GR, LWR and other cross roller slides.
With roller holders.
Working temperature up to 105°C
Applicable to automatics, mechatronics, optomechanics.
Technical drawing of RRK bearing cages
Dimension table of RRK bearing cages
Roller
diameter
Ø
Type
/symbol
Dimensions
Load capacity *
DW
t
A
d
e
C
[N]
CO
[N]
1.5
RRK1
1.5
3
3.5
0.45
2
36
58
2
RRK2
2
4
5
0.75
3
54
68
3
RRK3
3
5
7
1
3.5
132
160
6
RRK6
6
8.5
14
2.5
5
585
680
9
RRK9
9
14
20
3.5
8.5
1700
1830
12
RRK12
12
16
25
4.5
9
3000
3050
*) - Load capacity for 1 roller with the thrust force "F" in accordance to the drawing.
- C - dynamic load capacity, C0 - static load capacity
- The load capacity is calculated for guides with hardness of 60 +/- 2 HRc oand surface roughness of Ra<0.4.
- Load capacity of bearing cages is calculated on the basis of number of bearing needles mounted in the cage
- Length tolerance LK +0/-t
Weight table of RRK bearing cages
Table for weight values of bearing cages
(for the length of 100 rollers) [g]
Type/symbol
Plastic
RRK1
2.42
RRK2
6.0
RRK3
16.8
RRK6
160
RRK9
549.8
RRK12
1209.4
