Monorail MR - MR_W Carriages

General Information

MR linear carriages operate using roller bearings, which significantly increases the contact area between the rolling elements and the guide raceways. This results in substantially higher static and dynamic load capacities compared to similarly sized ball-type carriages.

Each carriage features four rows of roller bearings operating in a closed circuit. The carriages include an internal lubrication system and are equipped with debris wipers that  protect the rolling elements from external contamination.

Why Choose Schneeberger MRW Roller Carriages?

• Highest load capacity in its class
• Minimal deflection- thanks to the roller-raceway contact line and “O” geometry
• Stable performance under moment loads and in dynamic applications
• Optionally quipped with AMS Measurement Systems
• Compatible with centralized lubrication systems

MRW Linear Carriages

Size	A standard	B standard, long	C compact, high	D compact, high, long	E compact, high, for lateral fixation	F compact	G compact, long	P standardowa, extra long	Detailed Information
MR 25	MR W 25-A	MR W 25-B	MR W 25-C	MR W 25-D	MR W 25-E	MR W 25-F	MR W 25-G		(PDF)
MR 30	MR W 30-A	MR W 30-B	MR W 30-C	MR W 30-D		MR W 30-F	MR W 30-G
MR 35	MR W 35-A	MR W 35-B	MR W 35-C	MR W 35-D	MR W 35-E				(PDF)
MR 45	MR W 45-A	MR W 45-B	MR W 45-C	MR W 45-D		MR W 45-F			(PDF)
MR 55	MR W 55-A	MR W 55-B	MR W 55-C	MR W 55-D			MR W 55-G		(PDF)
MR 65	MR W 65-A	MR W 65-B	MR W 65-C	MR W 65-D				MR W 65-P	(PDF)
MR 100	MR W 100-A	MR W 100-B							(PDF)
Available Options for Monorail Carriages and Rails(PDF)

Available Accessories

Accessories	MR W 25	MR W 30	MR W 35	MR W 45	MR W 55	MR W 65	MR W 100
Additional wipers Viton Metal wipers	ZCV 25 ASM 25	ZCV 30 ASM 30	ZCV 35 ASM 35	ZCV 45 ASM 45	ZCV 55 ASM 55	ZCV 65 ASM65	ZCV 100 ASM 100
Bellows Adapter plate for bellows End plate for bellows	FBM 25 ZPL 25 EPL 25	- - -	FBM 35 ZPL 35 EPL 35	FBM 45 ZPL 45 EPL 45	FBM 55 ZPL 55 EPL 55	FBM 65 ZPL 65 EPL 65	- - -
Assembly rail	MRM 25	MRM 30	MRM 35	MRM 45	MRM 55	MRM 65	MRM 100
Lubrication plate	SPL 25-MR	SPL 30-MR	SPL 35-MR	SPL 45-MR	SPL 55-MR	SPL 65-MR	SPL 100-MR
Cross wiper	QAS 25-STR	QAS 30-STR	QAS 35-STR	QAS 45-STR	QAS 55-STR	QAS 65-STR	QAS 100-STR

Designation Method
