Linear ball bearings
Linear ball bearings are a crucial component of any linear guidance system. They enable smooth, precise, and failure-free motion along precision shafts, while minimizing friction and component wear.
LME
LME-type linear ball bearing
Standars series; plastic ball retainer version
Standars series; plastic ball retainer version
Technical drawing of LME type linear ball bearing.
Dimension table of LME type linear ball bearing.
|
Type
|
Ød
|
ØD
|
L
|
L1
|
L2
|
ØD1
|
h
|
W
|
(°)
|
G
|
Dyn. load capacity
C* [N] |
Stat. load capacity
C0* [N] |
Weight
[kg] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LME-05
|
5
|
12
|
22
|
14.5
|
1.1
|
11.5
|
1.0
|
-
|
-
|
-
|
270
|
270
|
0.01
|
|
LME-08
|
8
|
16
|
25
|
16.5
|
1.1
|
15.2
|
1.0
|
-
|
-
|
-
|
350
|
410
|
0.02
|
|
LME-12
|
12
|
22
|
32
|
22.9
|
1.3
|
21.0
|
1.5
|
7.5
|
78
|
0
|
555
|
800
|
0.04
|
|
LME-16
|
16
|
26
|
36
|
24.9
|
1.3
|
24.9
|
1.5
|
10.0
|
78
|
0
|
1045
|
910
|
0.06
|
|
LME-20
|
20
|
32
|
45
|
31.5
|
1.6
|
30.3
|
2.0
|
10.0
|
60
|
0
|
1170
|
1400
|
0.09
|
|
LME-25
|
25
|
40
|
58
|
44.1
|
1.85
|
37.5
|
2.0
|
12.5
|
60
|
1.51)
|
1330
|
1600
|
0.21
|
|
LME-30
|
30
|
47
|
68
|
52.1
|
1.85
|
44.5
|
2.0
|
12.5
|
50
|
2,0
|
2120
|
2800
|
0.32
|
|
LME-40
|
40
|
62
|
80
|
60.6
|
2.15
|
59.0
|
3.0
|
16.8
|
50
|
1.5
|
2920
|
4100
|
0.70
|
|
LME-50
|
50
|
75
|
100
|
77.6
|
2.65
|
72.0
|
3.0
|
21.0
|
50
|
2.52)
|
5195
|
8100
|
1.13
|
|
LME-60
|
60
|
90
|
125
|
101.7
|
3.15
|
86.5
|
3.0
|
27.2
|
54
|
02)
|
6390
|
10200
|
2.05
|
| All dimensions in the table are in [mm], unless stated otherwise. *Load capacity values are given for hardened and ground precision shafts (min. 59 HRC) *For precision linear shafts of lower hardness, the effective load capacitied equal: - for WRA: Cef = 0,74·C Coef=0,8·Co - for WRB: Cef = 0,63·C Coef=0,7·Co 1) Ø3 hole: hole for positioning below centerline 2) Ø5 hole: hole determining position |
|||||||||||||
Designation Method
|
|
LME
|
20
|
UU
|
OP |
|---|---|---|---|---|
| Series | ||||
| Size | ||||
| Internal wipers | ||||
| OP: open type AJ: adjustable type |
